ANISH - NUT CRIMPING MACHINE -70 MM ACROSS FLAT HEX NUT :


    We are Manufacturer, Supplier, Exporter of Nut Crimping Machines, Hydraulic Nut Crimping Machines and our set up is situated in Pune, Maharashtra, India.


  •   This machine provides accurate and fast operation of Crimping Nut on end of Hydraulic hoses and fittings.
  •   A centering pin is provided for adjusted vertically according to job requirement. The depth of Crimping is accurately set on Micrometer.The machine operates on Auto/manual mode.

TECHNICAL SPECIFICATIONS :

CRIMPING FORCE 50 Tons
MAX. OPENING (MM) 15 MM
MASTER DIE SHOE LENGTH 20
RANGE OF CRIMPING 66
ELECTRIC MOTOR H.P 1.5 H.P., 3 Phase, 415v
PUMP 6 L/min
SIZE L X W X H 900 X 500 X950
WEIGHT 200 KGS

DIE SETS :

  •   Die sets are fitted on the master die shoe by tightening Allen headed cap screw.
  •   The size is defined on the basis of perfect circle formed by the radial movement of the eight segments.

The suggested die sets :

  •   Die. 12, 14, 16, 19, 22, 24, 27, 30, 34, 39, 42, 45, 49, 65.

  •   Any die size other than standard can be supplied upto max A/F - 70mm against special order.
